Indo Alusys Industries Limited
Manufacturing Cables that are totally at par with the international standards
Slide

Cable

Aerial Bunched Cables

Distributing power to individual consumers by utility service providers like Electricity Boards/ Distributing authorities have widely accepted the novel concept of Overhead Power Distribution through Aerial Bunched Conductor over the bare conductor overhead distribution system. When compared to the conventional, ABC provides higher safety and reliability, lower power losses and ultimate system economy by reducing installation, maintenance and operative cost. This system is ideal for rural distribution and especially attractive for installation in difficult terrains such as hilly areas, forest areas, coastal areas etc. These cables are being designed, manufactured & tested conforming to IS: 14255, IS: 6474 or REC & other international specifications. ABC is also considered to be the choice for power distribution in congested urban areas with narrow lanes and by-lanes. In developing urban complex, ABC is the better choice because of flexibility for re-routing as demanded by changes in urban development plan.

XLPE/PVC Insulated Power & Control Cables of "INDO CABLE" brand of voltage grade 650/1100 Volts provided with ISI marking against IS:7098, IS:1554 & IS:694 (for flexible) are regularly manufactured following stringent quality checks at all stages by sophisticated testing & measuring equipments in its modern state of-art located at Bhiwadi meeting huge demand in areas of Power Transmission & Distribution, Control Circuits in Power plants and other industrial installation and signaling network of Railways with or without FR/FRLS properties including House/Industrial wiring

LT XLPE Cables

Offering a wide gamut of L T XLPE cables of assorted Sizes & type are light in weight and carry higher current capacity. They are capable to withstand short circuit temperature and emergency overload. These cables consist of carbon and hydrogen compounds, which essentially contain low-density polyethylene molecules in the form of long flexible chains. On crosslinking, slippage between flexible chains can be prevented. Cross-linked polyethylene (XLPE) is a thermosetting compound. It softens at the melting point of polyethylene (85°C to 115°C) and assumes an elastic rubber like consistency, a property that it retains during further rise of temperature until it becomes carbonized without melting at 250°C to 300°C. All this strengthens LTTXLPE cables against stress cracking and gives them a greater resistance to fight ageing in hot air.

1.1 KV PVC Power Cables

The Power Cables are used underground as well as overhead transmission of power in power plants, industries, projects, Transmission & Distribution and all other electrical systems. Different combinations such as Aluminum, Copper conductors, round solid conductor, stranded conductors, sector shaped conductors, taped inner sheath, extruded inner sheath, Round steel and aluminum wire / Flat galvanized steel strip Armored/ unarmored, single/double outer sheathed etc. are available.

Types of insulation include PVC, HR PVC, and XLPE. The inner & outer sheaths can be PVC, HR PVC, FRLS, HR-FRLS or FR depending upon the application and requirement of customers.

INDO CABLE manufactures different types of cables with combinations of specifications as mentioned above as per IS 1554 Part I for cables up to 11000.

1.1 KV PVC Copper Power & Control Cables

These cables are also used for underground as well as overhead transmission of power to the control panels in Power plants, Industries, Project and all the electrical systems.

Different variations such as round solid conductor/stranded conductors, taped inner sheath/extruded inner sheath, Round steel/aluminum wire/Flat galvanized steel strip Armored/ unarmored, single/double outer sheathed etc. are available. Types of insulation include PVC, HR PVC. The sheath can be PVC, HR PVC, FRLS, FR or HR-FRLS depending upon the application. INDO CABLE manufactures all above combinations as of 1.1 KV Qrade Control cables as per IS 1554 Part I from two cores to 61 cores in 1.5 and 2.5 sq. mm sizes.
